Advanced Technology Sesame CCD Optical Color Sorter With High Resolution Ratio

    Buy cheap Advanced Technology Sesame CCD Optical Color Sorter With High Resolution Ratio from wholesalers

    Buy cheap Advanced Technology Sesame CCD Optical Color Sorter With High Resolution Ratio from wholesalers
    • Buy cheap Advanced Technology Sesame CCD Optical Color Sorter With High Resolution Ratio from wholesalers

    Advanced Technology Sesame CCD Optical Color Sorter With High Resolution Ratio

    Ask Lasest Price
    Brand Name : Sortdek
    Model Number : GS6
    Certification : ISO9001, CE
    Payment Terms : L/C, D/P, T/T
    Supply Ability : 500 sets per month
    Delivery Time : 15 days
    Price : Negotiable
    • Product Details
    • Company Profile

    Advanced Technology Sesame CCD Optical Color Sorter With High Resolution Ratio

    Advanced Technology Sesame CCD Color Sorter With High Resolution Ratio


    Description:

    1. Multi-core parallel processing system
      Color selection, shape selection, smart selection scheme flexible matching synchronous operation
      2.High-quiet image acquisition system
      1.9Billion-pixel HD image, micron-level recognition accuracy, nonlinear distortion auto-correction fidelity
      3.visual interface
      Color selection effect try to show, adjust parameters more intuitive
      4. Large output production
      Ultra-wide channel, increased single-channel yield by more than 25%
      5. One-click intelligence
      Good or bad identification, one-click intelligent operation
      6. Cloud Connect System
      Internet + technology, mobile app smart color selection butler, remote control, real-time online analysis, diagnostic functions
      7. Big Data
      Massive database, extensive sesame material solutions, one-machine multi-select.
      8. Intelligent magnetically controlled high-frequency solenoid valve
      National patent, high frequency low consumption, wear-resistant lifetime matching use

    Applications:


    Sorting effect

    The machine can separate the raw material to qualified and reject.


    Specifications:

    ModelOutput(T/H)CarryoverPower(KW)VoltageWeight(kg)Dimension(mm)
    GS10.5-3>10:10.3-0.5220V/50HZ240975*1550*1400
    GS21-6>10:10.4-0.65220V/50HZ5001240*1705*1828
    GS31.5-9>10:10.7-1.1220V/50HZ8001555*1707*1828
    GS42-12>10:10.7-1.1220V/50HZ10001869*1707*1828
    GS52.5-15>10:10.7-1.1220V/50HZ11002184*1707*1828
    GS63-18>10:11.1-1.9220V/50HZ13502500*1707*1828
    GS73.5-21>10:11.1-1.9220V/50HZ13502814*1707*1828
    GS82.5-15>10:11.3-2.2220V/50HZ15003129*1707*1828
    GS105-30>10:11.4-2.3220V/50HZ17503759*1710*1828
    GS124-25>10:11.4-2.3220V/50HZ19004389*1710*1828
