High Accuracy Grain Color Sorter Five Channel For Oat Wheat Corn
Material
Quick Detail:
| Model | Output(T/H) | Carryover | Power(KW) | Voltage | Weight(kg) | Dimension(mm) |
| GW5 | 2.5-15 | >10:1 | 0.7-1.1 | 220V/50HZ | 1100 | 2184*1707*1828 |
Description:
(1) LED: Germany OSRAM;high brightness, life-time up to 100,000
hours, and equipped with intelligent control dimming technology;
(2) Sensor: Japanese TOSHIBA ;Industrial color CCD of 160 million
pixels, line frequency ≥ 10K, the minimum area of different colors
can be up to 0.0004 square millimeters;
(3) Lens: Japanese NIKON, optical industry customized lens, with
150 line pairs of ultra-high resolution, low distortion: <0.2%,
low color difference: <0.1 pixel, better imaging performance;
(4) Processor: ALTERA programmable logic device processor: data
processing speed>5500k bits; data transmission speed> 210mhz;
the system data acquisition and processing speed >3.125 Gbps, is
extremely high;
(5) Solenoid valve: customized solenoid valve for color sorter; All
imported alloy materials, MATRIX technology introduced in Italy,
shutdown time: <0.05ms, life: >10 billion times;
(6) Operation interface: 12-inch HD industrial computer, Intel CPU,
Windows operating system, 24-bit true color display, more realistic
image display;
(7) Intelligent operation interface, visual analysis of images,
one-click analysis of the proportion of impurities to be removed
and transfer of sorting parameters, easier operation;
(8) Support remote control for mobile phone apps and monitoring
equipment operation, convenient and fast;
(9) Support Internet remote control, system upgrade function, HD
image acquisition, visual system adaptive correction technology,
self-learning statistical analysis technology, and one-key
automatic parameter adjustment technology；
(10) IR cameras are optional to be added.
Applications:
The machine is used to sort the reject material, small stick and
other impurity from raw material of wheat.
And other small grain material, like oat, barley, buckwheat, corn,
myotonin.
Specifications:
| Model | Output(T/H) | Carryover | Power(KW) | Voltage | Weight(kg) | Dimension(mm) |
| GW1 | 0.5-3 | >10:1 | 0.3-0.5 | 220V/50HZ | 240 | 975*1550*1400 |
| GW2 | 1-6 | >10:1 | 0.4-0.65 | 220V/50HZ | 500 | 1240*1705*1828 |
| GW3 | 1.5-9 | >10:1 | 0.7-1.1 | 220V/50HZ | 800 | 1555*1707*1828 |
| GW4 | 2-12 | >10:1 | 0.7-1.1 | 220V/50HZ | 1000 | 1869*1707*1828 |
| GW5 | 2.5-15 | >10:1 | 0.7-1.1 | 220V/50HZ | 1100 | 2184*1707*1828 |
| GW6 | 3-18 | >10:1 | 1.1-1.9 | 220V/50HZ | 1350 | 2500*1707*1828 |
| GW7 | 3.5-21 | >10:1 | 1.1-1.9 | 220V/50HZ | 1350 | 2814*1707*1828 |
| GW8 | 4-23 | >10:1 | 1.3-2.2 | 220V/50HZ | 1500 | 3129*1707*1828 |
| GW10 | 5-30 | >10:1 | 1.4-2.3 | 220V/50HZ | 1750 | 3759*1710*1828 |
| GW12 | 6-32 | >10:1 | 1.4-2.3 | 220V/50HZ | 1900 | 4389*1710*1828 |
