Pulse Grain Sorting Machine A6 Color Sorter With High Accuracy
Large Output
Quick Detail:
| Model | Ejectors | Chutes | Power | Voltage | Air pressure | Air consumption | Weight | Dimension |
| (pcs) | (pcs) | (KW) | (V) | (Mpa) | (m³/min) | (kg) | (mm) |
| A2 | 128 | 2 | 1.1 | 220V/50HZ | 0.6-0.8 | <4.0 | 500 | 1240*1705*1828 |
Description:
(1) Support Internet remote control, system upgrade function, HD
image acquisition, visual system adaptive correction technology,
self-learning statistical analysis technology, and one-key
automatic parameter adjustment technology；
(2) Processor: ALTERA programmable logic device processor: data
processing speed>5500k bits; data transmission speed> 210mhz;
the system data acquisition and processing speed >3.125 Gbps, is
extremely high;
(3) Intelligent operation interface, visual analysis of images,
one-click analysis of the proportion of impurities to be removed
and transfer of sorting parameters, easier operation;
(4) Sensor: Japanese TOSHIBA ;Industrial color CCD of 160 million
pixels, line frequency ≥ 10K, the minimum area of different colors
can be up to 0.0004 square millimeters;
(5) Operation interface: 12-inch HD industrial computer, Intel CPU,
Windows operating system, 24-bit true color display, more realistic
image display;
(6) LED: Germany OSRAM;high brightness, life-time up to 100,000
hours, and equipped with intelligent control dimming technology;
(7) Lens: Japanese NIKON, optical industry customized lens, with
150 line pairs of ultra-high resolution, low distortion: <0.2%,
low color difference: <0.1 pixel, better imaging performance;
(8) Solenoid valve: customized solenoid valve for color sorter; All
imported alloy materials, MATRIX technology introduced in Italy,
shutdown time: <0.05ms, life: >10 billion times;
(9) Support remote control for mobile phone apps and monitoring
equipment operation, convenient and fast;
(10) IR cameras are optional to be added.
Paremeter
| Model | Ejectors | Chutes(pcs) | Power(KW) | Voltage | Air pressure | Air consumption (m³/min) | Weight(kg) | Dimension(mm) |
| A1 | 64 | 1 | 0.8 | 220V/50HZ | 0.6-0.8 | <1 | 240 | 975*1550*1400 |
| A2 | 128 | 2 | 1.1 | 220V/50HZ | 0.6-0.8 | <1.8 | 500 | 1240*1705*1828 |
| A3 | 192 | 3 | 1.4 | 220V/50HZ | 0.6-0.8 | <2.5 | 800 | 1555*1707*1828 |
| A4 | 256 | 4 | 1.8 | 220V/50HZ | 0.6-0.8 | <3.0 | 1000 | 1869*1707*1828 |
| A5 | 320 | 5 | 2.2 | 220V/50HZ | 0.6-0.8 | <3.5 | 1100 | 2184*1707*1828 |
| A6 | 384 | 6 | 2.8 | 220V/50HZ | 0.6-0.8 | <4.0 | 1350 | 2500*1707*1828 |
| A7 | 448 | 7 | 3.2 | 220V/50HZ | 0.6-0.8 | <5.0 | 1350 | 2814*1707*1828 |
| A8 | 512 | 8 | 3.7 | 220V/50HZ | 0.6-0.8 | <6.0 | 1500 | 3129*1707*1828 |
| A10 | 640 | 10 | 4.2 | 220V/50HZ | 0.6-0.8 | <7.0 | 1750 | 3759*1710*1828 |
| A12 | 768 | 12 | 4.8 | 220V/50HZ | 0.6-0.8 | <8.0 | 1900 | 4389*1710*1828 |
Application
